Battery Testing Solutions

Energy Storage Test System

For mission-critical applications, researchers and manufacturers need to know without a doubt that batteries are charged and will keep a charge. Our Energy Storage Testing instrument (ESTi™), a commercial off-the shelf, PC-based modular battery test solution, offers highly accurate measurements at a fraction of the cost of a custom test system.

This system’s highly intuitive ESTiViewTM drag-and-drop software powers the ESTi platform. You can quickly program charge, discharge, pulse, and ramp parameters to reflect exactly what you need to measure. You can also easily modify parameters based on changing application needs, create custom reporting dashboards, drag-and-drop module tests, and provide meaningful and actionable data from tests.

ESTiBox_kj1b copy

VENABLE ENERGY STORAGE TESTING INSTRUMENT

Key Features

noun_Brain_163918_04015c

Intuitive User Interface

Intuitive ESTiView software that provides a flexible, drag-and-drop graphical user interface (GUI) to easily create and manage battery test programs

Learn More About ESTiView
Harsh Environments

The Only Instrument on the Market with Wide Thermal Calibration Support

Instruments are thermally calibrated for operation in an ambient temperature range of 0°C to 50°C, making them ideal for use in harsh environments

Scalable system

Scalability

Test multiple cells simultaneously in a multi-node environment, easily upgrade to increase testing capacity as your application needs evolve

Advanced Capabilities in One Machine

Advanced Capabilities in One Machine

ESTi combines capabilities of several custom batttery test systems into a single instrument delivering the lowest cost-per-watt testing capacity on the market

The Venable Difference

Battery Test Products

Battery Test Equipment

ESTi 2161

6V, 1A programmable power source/sink; ESTiView V1.1.

Charge and Discharge Battery

ESTi 2165

6V, 5A programmable power source/sink; ESTiView V1.1.

Energy Storage Analysis

ESTi 2185

18V, 5A programmable power source/sink; ESTiView V1.1.

Energy Storage Testing

ESTi 2361 with EIS

6V, 1A programmable power source/sink; ESTiView V1.1. 2361 includes AC test capabilities (10uHz-200kHz) for Electrochemical Impedance Spectroscopy and AC Voltammetry.

Energy Storage Testing Equipment

ESTi 2365 with EIS

6V, 5A programmable power source/sink; ESTiView V1.1. 2365 includes AC test capabilities (10uHz-200kHz) for Electrochemical Impedance Spectroscopy and AC Voltammetry.

Electrochemical Impedance Spectroscopy

ESTi 2385 with EIS

18V, 5A programmable power source/sink; ESTiView V1.1. 2385 includes AC test capabilities (10uHz-200kHz) for Electrochemical Impedance Spectroscopy and AC Voltammetry.

Electrochemical Techniques Supported

Electrochemical Techniques Supported

  • Constant Charging and Discharging (current or voltage)
  • Constant Power or Load
  • Linear Sweep Voltammetry (LSV)
  • Cyclic Voltammetry (CV)
  • Step Voltammetry
  • Pulse Voltammetry [e.g., square wave voltammetry (SWV)]
  • Electrochemical Impedance Spectroscopy
  • Potentiostatic Intermittent Titration (PITT)
  • Galvanostatic Intermittent Titration (GITT)
  • AC Voltammetry

Learn More
Battery Testing Applications

Applications

  • Corrosion Measurement
  • Energy Device Testing {e.g., Batteries]
  • Electrolysis
  • Fuel Cells
  • Coating Evaluation
  • Sensors

THE VENABLE DIFFERENCE

Features that Put You in the Driver's Seat

SCALABILITY

Venable's modular architecture supports instrument scalability, protecting your investment.

noun_Texas_526575 (1)

Based in Austin, Texas, USA, Venable Instruments provides direct support for technical and application questions, calibrations, and repairs.

noun_credit_628652

Venable Instruments rents FRAs and the ESTi on a monthly basis and supports a lease to own program.

warranty

Venable provides a standard one year warranty which covers any defects in material or workmanship on new instruments. Optional 3 and 5 year extended warranties are available.

Request a quote

VENABLE INSTRUMENTS SUPPORT

Venable Provides the Support Necessary to Ensure Your Success

Telephone and Email Support

Telephone and Email Support

Venable is one of the only instrument manufacturers that offers telephone support (during normal US business hours) and by email with our experienced team of engineers

Learn More
Onsite Engineering Consultation

Onsite Engineering Consultation

Our customers see us as an extension of their own engineering teams, which sometimes means filling in internal resource gaps

Learn More
Repairs and RMAs

Repairs and RMAs

If we can’t resolve it by telephone or email, a Return to Manufacturer Authorization (RMA) will be promptly provided.

Learn More
Instrument Calibrations

Instrument Calibrations

Calibration is essential for confidence in your instrument’s accuracy, so you can be assured that the reading you obtain from your instrument is accurate.

Learn More
battery test

ELECTROCHEMICAL IMPEDANCE SPECTROSCOPY:

PROVIDING BETTER BATTERY CELL INSIGHT

A growing dependency on batteries requires diagnostics to maintain or predict battery reliability. There were many battery testing methods available, such as voltage reading, Coulomb counting and so on. However, these methods seldom provide full scale accuracy or have long testing periods, becoming a limiting step in battery processing throughput. This created a need for not only accurate but fast testing technologies for energy storage devices with good demonstration of reliability and repeatability.



Download White Paper
