RLC measurement is one of the many uses of the Venable Frequency Response Analysis Systems.  The RLC Measurement Kit provides an accurate, easily used tool for measuring values of resistors, inductors, and capacitors, and additional parasitic elements. For example, the user can simultaneously measure the capacitance, ESR, and ESL of a capacitor.  In this video Rajab Legnain, Software Developer at Venable Instruments, will walk through set up of the RLC Measurement Package along with a Venable 6340 FRA to measure and characterize the impedance easily and accurately.
